DR-B185HT 2M Mobile Transceiver
The Alinco DR-B185HT is a powerful 2M mobile transceiver designed for reliable communication. It boasts an impressive 85-watt maximum output and uses a high-stability PLL synthesizer for exceptional signal clarity. This transceiver features a clear 7-digit alphanumeric display and a versatile scanning function, making it adaptable for various communication needs. Its user-friendly interface ensures straightforward operation. With 500 memory channels, Wide and Narrow FM modes, and CTCSS/DCS/2-Tone capabilities, it offers comprehensive functionality for demanding users.
$149.00
Owner Satisfaction
4.4
/ 5
Category Rank
190
/ 302
#190 in Two-Way Radios
Price vs Category Average
-70%
Below average
Frequency coverage
144.000147.995136.000173.995
/ TX: - MHz, RX: - MHz
Who it's for
- High Power Output (85W)
- Rugged and User-Friendly Design
- Excellent Thermal Management
Who should skip it
- Single Band Operation (VHF Only)
- Limited Advanced Features
- Large Physical Footprint
Key Specs
Frequency coverage
TX:144.000 - 147.995MHz, RX:136.000 - 173.995MHz
Operating mode
16k0F3E (FM/wide)/11k0F3E (FM/narrow)
Antenna impedance
50ohm unbalanced
Frequency stability
+/- 2.5ppm
Power supply requirement
13.8V DC +/- 15%
Current drain
Receiver: 1.0A (max.), Transmit: 20A
Dimensions (w/o projection)
164 x 44 x 183.6 mm
Weight
1.5 Kgs
Features
- High-stability PLL synthesizer for precise frequency control.
- Powerful 85W maximum power output.
- Clear 7-digit alphanumeric display.
- Versatile scanning features for efficient monitoring.
- User-friendly interface for simple operation.
- Front panel speaker for clear audio.
- Supports Wide and Narrow FM modes.
- CTCSS/DCS/2-Tone encode and decode.
What customers say
This transceiver earns high praise primarily for its exceptional power and reliability. Operators value the robust 85-watt output, which ensures excellent reach for mobile and base use where strong signals are essential. Users appreciate the straightforward, no-nonsense design and simple programming, favoring its functional approach over complex competitors. While the unit performs outstandingly for its price, extended high power operation can generate significant heat, requiring attention to ventilation. Though the build is solid, the included microphone is often considered basic. Overall, the DR-B185HT is highly recommended for operators prioritizing maximum dependable power in a budget friendly package.
