Icom
IC-9700 VHF/UHF/1.2GHz SDR Transceiver
Best all-mode transceiver for serious satellite and digital radio enthusiasts.
Explore new communication horizons with the ICOM IC-9700, a versatile VHF/UHF/1.2 GHz SDR transceiver. Designed for enthusiasts, it features direct-sampling SDR for 2m/70cm and down-conversion for 23cm, ensuring exceptional receiver clarity. Enjoy robust RF output with 100W on 2m, 75W on 70cm, and 10W on 23cm. This all-mode transceiver supports traditional modes alongside D-STAR digital voice and data. Navigate effortlessly with its 4.3-inch TFT touchscreen, offering real-time spectrum scope and waterfall displays for optimal band monitoring. Experience advanced features like full-duplex operation and built-in DV Gateway for seamless internet connectivity.
$2099.95
Owner Satisfaction
4.7
/ 5
Category Rank
13
/ 302
#13 in Two-Way Radios
Price vs Category Average
+322%
Above average
RF Output
10021441487570430450102312401300
/ Watts on m (- MHz), Watts on cm (- MHz), Watts on cm (- MHz)
Who it's for
- Operators seeking versatile multi-band and digital mode capabilities
- Serious hobbyists demanding superior signal clarity and sensitivity
- Satellite enthusiasts requiring simplified tracking and intuitive controls
Who should skip it
- Casual hobbyists on a strict budget
- Advanced users prioritizing peak performance on the 1.2GHz band
- Long-distance communicators needing high power without external equipment
Performance breakdown
Receiver Clarity
Direct-sampling SDR architecture delivers exceptional signal definition across all bands.
Satellite Versatility
Full-duplex operation and precise tracking make satellite communication effortless and reliable.
Interface Usability
The high-definition touchscreen simplifies complex band monitoring and menu navigation.
Digital Integration
Built-in D-STAR and DV Gateway support provide seamless modern digital connectivity.
RF Output Power
Robust power levels on 2m and 70cm ensure strong, reliable transmissions.
Frequency Stability
High-precision internal clocking maintains rock-solid stability during long-duration operations.
Key Specs
RF Output
100 Watts on 2m (144-148 MHz), 75 Watts on 70cm (430-450 MHz), 10 Watts on 23cm (1240-1300 MHz)
Modes
FM, SSB, AM, CW, RTTY, Digital, D-Star Digital Voice and Digital Data
Dimensions
9.45 in. W x 3.70 in. H x 9.37 in. D
Weight
10.400 lbs.
Frequency Stability
+/- 0.5ppm (–10°C to +60°C)
Antenna Connectors
2m SO-239, 70cm Type N, 1.2 GHz Type N
Input Voltage
13.8 Vdc
Maximum Current
20.0 A
Features
- Direct-sampling SDR for superior receiver performance
- All modes supported, including D-STAR digital
- Full duplex and dualwatch capabilities
- Smooth satellite operations with normal/reverse tracking
- High-definition 4.3-inch TFT touchscreen
- Real-time spectrum scope and waterfall display
- Built-in DV Gateway for internet connectivity
- Intuitive touchscreen interface for easy navigation
What customers say
The Icom IC-9700 is highly regarded by VHF/UHF/1.2GHz enthusiasts, especially for satellite work and weak signal communication. Users consistently praise its exceptional receiver sensitivity, attributing this performance to its dedicated SDR architecture across all bands. The integrated satellite mode and responsive color touchscreen simplify complex operations, enhancing user-friendliness. Its dedicated 1.2GHz capability further solidifies its leading position in the market. While the initial investment is significant, operators focused on performance above 50 MHz find the superior technology and benchmark capabilities justify the premium price. Overall, the sentiment confirms the IC-9700 as the current standard for high-tier VHF/UHF performance.
Know before you buy
Yes, the transceiver is well-suited for satellite work. It features full-duplex operation and normal/reverse tracking, which simplifies the process of staying on frequency during satellite passes.
Absolutely. The IC-9700 natively supports D-STAR digital voice and data modes, and it includes a built-in DV Gateway function for seamless internet connectivity without needing an external terminal.
The 2m and 70cm bands utilize RF direct sampling for superior clarity and performance. The 1.2 GHz band uses a down-conversion IF sampling method to maintain high signal integrity.
Yes, the IC-9700 features dualwatch capability, allowing you to monitor two different bands simultaneously. You can also view real-time spectrum scope and waterfall displays for both bands on the 4.3-inch touchscreen.
The radio requires a 13.8 Vdc power source. It draws a maximum current of 20.0 Amps, so ensure your power supply is rated to handle this load during full-power transmissions.
Yes, because this is an amateur radio transceiver capable of transmitting on VHF and UHF bands, you must hold a valid amateur radio license issued by your country's regulatory authority to operate it legally.
