Matrox
Monarch HDX
The Matrox Monarch HDX is a professional dual-channel H.264 video encoder built for simultaneous streaming and recording. It seamlessly handles both SDI and HDMI inputs, offering independent encoding for each channel. This flexibility supports diverse workflows, such as streaming to multiple destinations or capturing master and proxy files from a single source. Ideal for live streaming, broadcast, and production, the Monarch HDX supports SD and HD resolutions, features a high-quality scaler and de-interlacer, and provides 0-frame latency on SDI loopthrough for effortless integration into any setup.
$1295.00
Owner Satisfaction
4.4
/ 5
Category Rank
147
/ 235
#147 in Video Editing Hardware & Production Equipment
Price vs Category Average
-20%
Below average
Video Encoder Type
.264410
/ H/MPEG- Part (AVC)
Who it's for
- Simultaneous Dual-Channel Operation
- Versatile Professional Connectivity
- Dedicated Hardware Reliability
Who should skip it
- Premium Price Point
- Lack of HEVC/H.265 Support
- Single-Purpose Hardware Limitation
Key Specs
Video Encoder Type
H.264/MPEG-4 Part 10 (AVC)
Input/Output Interfaces
1x SDI In, 1x HDMI In, 1x SDI Out (Passthrough), 1x HDMI Out (Preview)
Maximum Encoding Resolution
1920 x 1080
Maximum Frame Rate
60 fps (up to 30 fps at 1080p)
Audio Input
Embedded (HDMI/SDI) or 1/8" Analog Stereo (Line level)
Connectivity
RJ45 Ethernet (10/100/1000 Base-T), 2x USB 2.0, 1x SD Card Slot
Power Consumption
20 to 30 W typical, 42 W maximum
Dimensions
5.6 x 8.5 x 1.4" (Main Body)
Features
- Dual H.264 encoders for independent streaming/recording
- Simultaneous SDI and HDMI input/output
- Records high-quality MP4 and MOV files
- 0-frame latency SDI loopthrough
- Supports RTMP and RTSP streaming protocols
- Records to USB drives or SD cards
- Integrated high-quality scaler and de-interlacer
- Web-based control via Command Center software
What customers say
Professionals highly value the Matrox Monarch HDX for its exceptional reliability and robust dual channel capability. Users confirm it functions as a true workhorse, flawlessly streaming and recording high quality H.264 video simultaneously in critical settings. The resulting video output is consistently pristine, affirming its professional grade status. While performance is top tier, the initial setup presents a learning curve, as the interface is functional but not highly intuitive for newcomers. The premium price point is a barrier for hobbyists. Ultimately, satisfaction is deep among those prioritizing industrial strength stability and flawless operation over simplicity or low cost, viewing this dependability as justifying the investment.
