Gefen
Gefen 4x4 Seamless Matrix for HDMI
The Gefen 4x4 Seamless Matrix for HDMI offers advanced control and distribution of high-definition video signals. This matrix accepts four HDMI sources, individually scaling each to any of the four connected HDTV displays without any delay or frame loss. It supports resolutions up to 1080p Full HD and WUXGA, ensuring crisp visuals. Flexible control options include the front panel, IR remote, RS-232, and IP connectivity. With the ability to store ten custom routing presets and an intuitive on-screen GUI, managing complex video setups is simplified.
$1649.00
Owner Satisfaction
4.4
/ 5
Category Rank
297
/ 920
#297 in HDMI Splitters & Switches
Price vs Category Average
+63%
Above average
Number of Inputs
4
/ HDMI Type A, female, locking
Who it's for
- True Seamless Switching
- Flexible 4x4 Matrix Routing
- Robust Professional Build Quality
Who should skip it
- High Cost of Entry
- Complex Setup and Integration
- Potential for HDMI Standard Limitations
Key Specs
Number of Inputs
4 HDMI Type A, female, locking
Number of Outputs
4 HDMI Type A, female, locking
Maximum Resolution Support
1080p Full HD and 1920x1200 (WUXGA)
Dimensions
16.9" x 1.7" x 7.9" (430mm x 42mm x 200mm)
Unit Weight
7 lbs. (3.2 kg)
Control Interfaces
RS-232, IP (DB-9), IR Extender (3.5mm)
Power Supply
12V DC, locking
Compliance
HDCP-compliant
Features
- Seamless matrix scales inputs without frame loss
- Ten user-configurable routing presets
- Intuitive on-screen Graphical User Interface
- Multiple control methods supported
- Field-upgradable firmware via web interface
- Rack-mountable enclosure included
- Seamless switching ensures no picture loss
- Supports resolutions up to 1080p/WUXGA
What customers say
This Gefen matrix is highly regarded by professionals for its exceptional reliability and seamless switching performance. Users consistently emphasize the instantaneous transitions, which are crucial for mission-critical AV setups where downtime is unacceptable. The robust build quality and extensive control options, like IP and RS-232 integration, are significant advantages for complex automation. While the performance is top tier once configured, the initial setup presents a steep learning curve. Novice users often find the configuration, firmware management, and troubleshooting compatibility challenging. Therefore, the product offers the best value to experienced integrators who can fully utilize its advanced capabilities.
