Camplex CMX-XBN04XM X-TREME 4-Channel OM3 Multimode Expanded Beam Fiber Cable - 50 Foot
Best rugged fiber cable for demanding outdoor broadcast and production environments.
The Camplex CMX-XBN04XM X-TREME 4-Channel OM3 Multimode Expanded Beam Fiber Cable is engineered for extreme durability in demanding production environments. This 50-foot cable ensures reliable signal transmission even when exposed to harsh conditions like dust, dirt, and liquids, thanks to its IP68-rated Neutrik FIBERFOX connectors. Designed for resilience, it offers cut-proof and rodent-resistant features, making it ideal for challenging outdoor applications. The cable's flame-retardant PUR jacket and aramid yarn provide excellent retention and longevity, fully compatible with MIL-DTL-83526 systems.
$1611.49
Owner Satisfaction
4.7
/ 5
Category Rank
74
/ 6543
#74 in Network Cables
Price vs Category Average
+350%
Above average
Fiber Type
4350
/ -Channel OM Multimode (µm Core)
Who it's for
- Production crews needing rapid, simplified cable deployment and management
- Field technicians working in rugged, outdoor broadcast environments
- Broadcast professionals requiring high-speed 10 Gigabit data transmission
Who should skip it
- Budget-conscious buyers needing cost-effective standard fiber solutions
- Engineers requiring minimal signal loss for long-distance data runs
- Users relying on standard, non-proprietary fiber optic infrastructure
Performance breakdown
Environmental Resilience
IP68 rating ensures total protection against dust, dirt, and liquid ingress.
Physical Durability
Cut-proof, rodent-resistant design thrives in the most punishing production environments.
Signal Integrity
Expanded beam technology maintains high-fidelity transmission despite harsh field conditions.
Deployment Versatility
Hermaphroditic connectors allow for direct daisy-chaining without needing extra couplers.
Thermal Stability
Operates reliably across an extreme temperature range from arctic to desert.
Build Quality
Flame-retardant PUR jacket and aramid yarn provide professional-grade structural longevity.
Key Specs
Fiber Type
4-Channel OM3 Multimode (50µm Core)
Connector Type
Neutrik FIBERFOX EBC25 Hermaphroditic
IP Rating
IP68 (mated and unmated)
Jacket Material
PUR Flame-retardant
Attenuation
Typical 1.5dB per Connection, Max 2.5dB per Connection
Operating Temperature
-51°F to 160°F (-46°C to +71°C)
Tensile Strength
1,800N
Compatibility Standard
MIL-DTL-83526
Features
- Resilient against dust, dirt, and liquids
- Cut-proof and rodent-resistant connectors
- IP68 rated for extreme environments
- High immunity via expanded beam technology
- Flame-retardant PUR jacket material
- Excellent cable retention via aramid yarn
- Designed for demanding outdoor applications
- Directly extendable without couplers
What customers say
Professional users highly value the Camplex XTREME cable for its exceptional durability and reliability in demanding broadcast and industrial settings. The Expanded Beam technology, featuring a noncontact lensing system, is a key benefit, drastically reducing failures caused by dirt and repeated connection cycles. This design minimizes field cleaning, ensuring faster setups and fewer signal interruptions during critical operations. While the initial cost is higher, customers agree the superior longevity and reduced maintenance offer excellent long-term value. Performance remains flawless, even in harsh environments. Users accept the inherent bulk as a necessary trade-off for unparalleled protection and guaranteed connectivity.
Know before you buy
Expanded beam technology uses lenses to expand the light signal across the connector interface, making the connection significantly less sensitive to dust, dirt, and debris compared to standard physical contact connectors. This ensures reliable performance in outdoor environments where cleaning fiber ends is often impractical.
Yes, the Neutrik FIBERFOX connectors are hermaphroditic, meaning they are designed to mate directly with each other. You can daisy-chain multiple cables together without needing separate couplers or gender changers.
While it is designed for demanding outdoor production environments, it is primarily built for temporary, high-traffic use. Its flame-retardant PUR jacket and rodent-resistant construction provide excellent durability, but it is best suited for applications where the cable needs to be deployed and retrieved repeatedly.
An IP68 rating indicates that the connectors are fully protected against dust ingress and can withstand submersion in water. This protection applies even when the connectors are unmated, providing peace of mind when working in wet or dusty conditions.
Yes, the Camplex CMX-XBN04XM is fully compatible with the MIL-DTL-83526 standard. It is designed to integrate seamlessly with other systems that adhere to this military-grade specification.
The aramid yarn provides high tensile strength and cable retention, which prevents the fiber strands from stretching or breaking when the cable is pulled or under tension. This is essential for maintaining signal integrity during the rigors of setup and teardown.
