EK-Quantum Vector RE RTX 3080/3090 Active Backplate D-RGB
The EK-Quantum Vector RE RTX 3080/3090 Active Backplate is designed to complement existing EK-Quantum Vector RE RTX 3080/3090 water blocks, actively cooling the backside of reference design NVIDIA GeForce RTX 3080 and 3090 GPUs. It integrates seamlessly with the water block via a new terminal, requiring only one inlet and outlet for a cleaner build. This active backplate directly cools critical PCB hotspots and VRAM on the rear of the GPU, utilizing a fin array with low flow restriction for efficient heat transfer and optimal cooling performance. The construction features a CNC-machined nickel-plated copper base and aluminum for the backplate, with a glass-like cast acrylic top.
$106.54
Owner Satisfaction
4.4
/ 5
Category Rank
1797
/ 3605
#1797 in Computer System Cooling Parts
Price vs Category Average
-29%
Below average
Dimensions
22312415
/ xxmm
Who it's for
- Superior VRAM Cooling
- Integrated D-RGB Aesthetics
- Comprehensive GPU Thermal Management
Who should skip it
- Significant Additional Cost
- Increased Build Complexity
- Niche Compatibility
Key Specs
Dimensions
223x124x15mm
D-RGB cable length
500mm
D-RGB LED count
8
D-RGB connector standard
3-pin (+5V, Data, Blocked, Ground)
Material
Nickel-plated electrolytic copper, Aluminum, Cast Acrylic
Compatibility
Reference design NVIDIA GeForce RTX 3080 and 3090 GPU
Not compatible with aluminum Fluid Gaming parts
Requires corrosion, scale, and biological inhibitors in coolant
Features
- Actively cools the backside of the GPU PCB and VRAM
- Integrates with EK-Quantum Vector RE RTX 3080/3090 water blocks for a unified cooling solution
- Features a fin array with 6 wide channels for very low flow restriction
- CNC-machined copper base for efficient heat transfer
- CNC-machined aluminum backplate
- Glass-like cast acrylic top cover
- Addressable D-RGB lighting with 8 individually controlled LEDs
- Compatible with popular RGB sync technologies
What customers say
Customers consistently praise the EK Quantum Vector RE RTX 3080/3090 Active Backplate for its exceptional build quality and striking D RGB design. Enthusiasts appreciate the premium materials and precise machining, which contribute to a robust and visually appealing component for high end custom water cooling loops. The integrated lighting seamlessly enhances system aesthetics, making it a favored choice for those prioritizing both superior craftsmanship and a sophisticated look in their PC builds. While a premium investment, its perceived quality and design often justify the cost for dedicated users.
