Musical Fidelity
Musical Fidelity M8x DAC
Best high-end DAC for audiophiles seeking pure, uncompromising sound quality.
The Musical Fidelity M8x DAC is a high-performance digital-to-analog converter designed to elevate your audio system. It features dual ESS ES9038Q2M Sabre DAC chips in a dual-mono, dual-differential configuration for exceptional clarity and a signal-to-noise ratio exceeding 120 dB. This DAC supports high-resolution formats including PCM up to 768 kHz and native DSD512, along with MQA decoding. It also functions as a powerful, fully balanced Class A headphone amplifier, delivering 3.2 watts into 32-ohm headphones. The M8x deliberately omits wireless connectivity to maintain signal purity, offering robust wired connections like USB-B, AES/EBU, S/PDIF, and I²S.
$4599.00
Owner Satisfaction
4.6
/ 5
Category Rank
240
/ 489
#240 in Audio Converters
Price vs Category Average
+5%
Above average
Dual-Mono, Dual-Differential Conversion
9038232
/ Two ESS ESQM -bit Sabre DAC chips
Who it's for
- Listeners prioritizing long-term durability and high-grade internal engineering
- Audiophiles seeking uncompromising sonic clarity and expansive soundstage depth
- System builders requiring flexible connectivity for diverse digital sources
Who should skip it
- Budget-conscious buyers looking for high-value entry-level equipment
- Space-constrained owners with limited rack or shelf capacity
- Convenience-seekers wanting an all-in-one streaming and conversion solution
Performance breakdown
Conversion Precision
Dual-mono architecture delivers exceptional clarity and industry-leading signal-to-noise performance.
Headphone Drive Capability
Class A amplification effortlessly powers even the most demanding high-impedance headphones.
Format Versatility
Native DSD512 and full MQA support cover every high-resolution audio requirement.
Connectivity Depth
Comprehensive wired inputs ensure maximum signal integrity for all digital sources.
Build Integrity
Robust aluminum chassis provides superior shielding and a premium tactile experience.
Jitter Control
Ultra-low clock jitter ensures a precise, natural, and open soundstage.
Key Specs
Dual-Mono, Dual-Differential Conversion
Two ESS ES9038Q2M 32-bit Sabre DAC chips
Signal-to-noise ratio
> 120 dB
Ultra-Low Jitter Clock
Total correlated jitter < 100 femtoseconds peak to peak
High-Resolution Format Support
PCM up to 32-bit/768 kHz, DSD256 via DoP, native DSD512 via USB
MQA Decoding
Full hardware MQA decoding on USB and all SPDIF inputs
Switchable Upsampling & Reclocking
Inputs
USB-B (asynchronous), AES/EBU (XLR), Coaxial S/PDIF, Optical S/PDIF (x3), I²S (HDMI)
Outputs
Balanced XLR (switchable fixed/variable), RCA (switchable fixed/variable), 6.3mm headphone jack, Balanced XLR headphone output (4-pin)
Features
- High-performance dual-mono, dual-differential DAC architecture for superior sound quality.
- Powerful, fully balanced Class A headphone amplifier capable of driving demanding headphones.
- Extensive connectivity options including USB, AES/EBU, S/PDIF, and I²S for maximum flexibility.
- Dedicated focus on signal purity by omitting wireless connectivity and utilizing an aluminum chassis for shielding.
- Supports the latest high-resolution audio formats, including PCM up to 768 kHz and native DSD512.
- Switchable upsampling and reclocking features allow for sound optimization based on source and preference.
- Variable output option enables use as a digital preamp with remote volume control.
- Robust build quality with discrete analog output stages for a natural and open sound.
What customers say
Customers consistently praise the Musical Fidelity M8x DAC for its exceptional sound quality, noting its ability to deliver a remarkably detailed and expansive audio experience. Many highlight the device's robust build and sophisticated design, which contributes to a premium feel. Users appreciate the clarity and musicality it brings to their systems, often describing it as a significant upgrade that elevates their listening pleasure. The M8x DAC is frequently regarded as a top tier performer in its category.
Know before you buy
Yes, the M8x features full hardware MQA decoding across its USB and all S/PDIF inputs, ensuring high-quality playback for MQA-encoded files.
Yes, the unit features switchable fixed or variable outputs on both XLR and RCA connections. This allows you to control volume directly from the DAC when connected to a power amplifier or active speakers.
Musical Fidelity intentionally omitted wireless connectivity to prioritize signal purity and minimize electromagnetic interference. This design choice ensures the cleanest possible audio path from your wired digital sources.
The M8x features a robust, fully balanced Class A headphone amplifier that delivers 3.2 watts into 32 ohms. It is designed to drive a wide range of headphones, from 8 ohms up to 300+ ohms, with ease and authority.
The I²S input provides a direct digital connection that separates the clock signal from the data, which can result in lower jitter and improved timing accuracy compared to standard S/PDIF connections when paired with a compatible source.
The M8x is compatible with both Windows and macOS. While it is plug-and-play for many applications, you will need to install the appropriate drivers to utilize ASIO or WASAPI protocols for bit-perfect high-resolution audio playback on Windows.
